Fill-It Flexible Wood Filler is the perfect partner to Smiths CPES for restoring wood. It is the Epoxy Wood Filler that lasts offering a permanent and watertight solution. Do it once, do it Right.
Smiths Fill-It Epoxy – Flexible Wood Filler Summary
- Long working time
- No sag
- Easy to work
- Easy to sand or carve
- Flexible – to the extent that wood is
- Cures down to -2 degrees (28°F)
- High strength – drilled or tapped for fasteners
- Waterproof – used below the waterline for boat hull repairs
- Permanent – do the job once
- Coloured to match the wood if desired
- No Shrinkage
Fill-It epoxy filler represents a breakthrough in the technology of filling compounds. using advanced hydrogen bonding technology, it creates a high strength, light weight, non-sagging, easily sanded epoxy filler. One part is an epoxy resin and the other a curing agent.
Both parts are derived from natural wood resins so they are extremely compatible with wood. If your filler does not flex with your wood – it won’t stay in your wood; that’s why you need a ‘flexible wood filler’ not a rigid one.
Use and Properties
The two components of Fill-It epoxy flexible wood filler are slightly different colours in order to aid in mixing. The mixed colour is off-white, but may be coloured if required. Mix the two components one to one by volume. You must use two different tools to remove identical amounts from each pot. If you do not have two palette knives or scrapers that will fit, our glue stirring sticks are ideal.
Mixed these two components become a gel that can be smoothed and worked to a feather edge. After one to two hours in moderate weather it begins to harden, and cures overnight.
Sand as soon as it does not gum up the paper or after the flexible wood filler has cured. Carving, drilling, sanding and tapping are easy once cured. Drill pilot holes to secure screws without cracking. Paint or Prime once finished – though we recommend a coat of CPES to promote adhesion of finishes to Fill-It.
Its compressive strength is so great that you can restore defects in ferro-cement boat hulls with it.
If has sufficient flexibility that it is suitable for wooden beams, windows and sills, doors or other parts of wood buildings as well as wood or fibreglass boat hull repair. This flexible wood filler will accomodate the movement and shocks associated with all of these constructions.
Waterproof Filler Application Techniques
Apply Fill-It first by forcefully smearing some against the surface. This ensures good adhesion of Fill-It epoxy filler to a surface. Build up to the desired thickness by applying more permanent epoxy filler.
Tool the uncured material smooth and level by placing a clean new piece of clear 4-mil or 6-mil polyethylene sheet over the uncured material. Use a squeegee or other tool to smooth the filler through the plastic. 4mil is 100 microns, or about the thickness of a piece of 80gsm copier paper. In the UK this relates to a decent quality carrier bag – a ‘bag for life’ if you will. Peel the plastic film off once the waterproof epoxy filler has cured fully. In order to ensure adhesion of whatever primer or paint is to be applied next, it is recommended that Fill-It epoxy flexible wood filler be sanded, and then lightly over coated with Smiths CPES, before painting.
Use over Smiths CPES
Fill-It bonds very strongly indeed to surfaces that have been treated with Smiths CPES (Clear Penetrating Epoxy Sealer). Ensure however that the solvents have evaporated fully prior to application. Your nose is normally adequate to determine this.
How Much Fill-It do I Need to fill my Rotten Wood?
Fill-It does not shrink, so a 355ml tub of Fill It will fill 355 cubic centimetres of void with no wastage. There are approximately 15 cubic centimetres in one cubic inch.
In the real world wastage does of course happen, so I would normally reckon filling voids of around 300 cubic centimetres or 20 cubic inches from a small Smiths Fill-It. If you have more ‘hole’ than that, you need the larger Smiths Fill-It, which contains 950ml of product, and will fill around 900 cubic centimetres or 60 cubic inches of void.
To calculate how much void you have look at the hole, and imagine it as a regular three dimensional rectangle (parallelepiped). Imagine a parallelepiped where the length, width and height are averages of the dimensions of the irregular hole.
Thus, your rotten window frame with a 1″ by 1/2″ by 4″ rotten section requires 4 * 1 * 0.5 = 2 cubic inches of filler, = 30 cubic centimetres (30ml) of Fill-It flexible wood filler to restore it.
|Package||MilliLitres (cc)||Cubic Inches|
|12 US Fl Oz||355||22|
|2 US Pint||950||58|
|1 US gallon||3785||231|
Mixing Smiths Fill-It Epoxy Filler
We have some specific notes on the thorough mixing of 2 part products on this mixing page, but reproduce the Fill-It specific details here:
Smiths Fill-It is a 2 part high quality epoxy resin filler. As such you MUST use two different tools to remove the part A and part B components.
Mixing ratios are 1:1 by volume, or 92 parts A to 100 parts B by weight.
Mix to within 10% accuracy to ensure best results. Use scales to weigh components if possible. Mixing to 10% accuracy can normally be achieved by eye and volume however.
Mix the two-components on a flat surface (a piece of scrap plywood or plastic is ideal) using a paint scraper, stiff-bladed putty knife or other similar tool. Use a smear-scrape-fold motion, scraping clean both the mixing surface and the tools occasionally.
Keep mixing until the colour is entirely uniform. For mixing to use under the waterline in boats, please read the more detailed Fill-It mixing instructions here. Mixed properly Fill-It is a permanent and waterproof epoxy filler.
The filler, if uniform in colour, is now ready to use.
Shelf Life and Storage
Unmixed Fill-It lasts pretty much forever. However, if stored in cold conditions (UK winters qualify here), you may notice that the blue part B component has formed crystals. This is not the product going off, but is reversible crystallisation within the very pure contents of part B. Heating reverses the process; we recommend loosening the lid slightly and warming the can by placing it in a saucepan of hot water and leaving it overnight. The crystals will have disappeared by the morning, making the flexible wood filler far easier to mix. You can also use a cool (50 centigrade) oven to good effect.
Colouring Epoxy Filler
Colour Fill-It using Iron Oxide pigments of paint quality during mixing. We sell a Colouring Kit that can achieve the tones of natural woods, and full instructions for colouring Fill-It can be found here.
Working and Cure times
Unset filler can be removed from tools with many solvents, including our Epoxy Clean Up Solvent, or elbow grease and an old rag.
Fill-It is both a powerful adhesive and a permanent filler. You cannot remove set filler from many surfaces. Consequently please clean tools thoroughly before the Fill-It sets hard.
Painting Over Fill-It Flexible Wood Filler
We really recommend a coat of CPES over cured Fill-It after sanding to promote paint or varnish adhesion. Fill-It and CPES can be purchased together t a discount as a Wood Rot Repair Kit from here.
